CBB65 round type dual capacitor

CBB65-2 metalized polypropylene AC capacitor

Features:

1. Round- shape metal case, two groups of lug terminals, and combing the capacitor of air conditioner compressor with the capacitor of fan.(C for public pole,HERM for compressor pole, FAN for the fan pole)

2. With inner anti-explosion device, safe and reliable.

3. Low dissipation factor, high insulation resistance ,good slef-healing, stable performance, good ability of resisting impact current and overload.

4.Suitble for air conditioner, refrgierator, washing machine, light etc and beneficial to the starting and running of AC motor.

Technical Data:

CBB65
Model		Size	Model		Size
CBB65/450V	5UF	40*55	CBB65/450V	20+1.5UF	50*75
	7.5UF	40*55		20+5UF	50*85
	10UF	40*65		25+1.5UF	50*85
	12.5UF	40*65		25+3UF	50*90
	15UF	40*75		25+5UF	50*100
	17UF	40*75		30+2UF	50*100
	20UF	45*75		30+5UF	50*100
	25UF	45*100		30+7.5UF	50*105
	25UF	50*75		35+2UF	50*105
	30UF	45*100		35+5UF	50*105
	30UF	50*85		35+7.5UF	50*105
	35UF	50*100		40+5UF	50*105
	35UF	50*85		40+5UF	50*120
	40UF	50*100		40+7.5UF	50*120
	45UF	50*100		45+5UF	50*120
	45UF	50*110		45+7.5UF	50*120
	50UF	50*100		50+5UF	50*120
	50UF	50*110		50+7.5UF	50*125
	50UF	50*120		55+5UF	55*125
	55UF	50*110		55+6UF	55*125
	60UF	50*125		55+7.5UF	55*125
	65UF	50*125		60+5UF	55*125
	70UF	55*125		60+6UF	55*125
	80UF	55*125		60+7.5UF	55*125
	100UF	60*125		65+5UF	55*125
CBB65/370V	5UF	40*55	CBB65/370V	20+1.5UF	50*75
	7.5UF	40*55		20+5UF	50*85
	10UF	40*65		25+1.5UF	50*85
	12.5UF	40*65		25+3UF	50*90
	15UF	40*75		25+5UF	50*90
	17UF	40*75		30+2UF	50*90
	20UF	45*75		30+5UF	50*95
	20UF	40*75		30+7.5UF	50*105
	25UF	50*75		35+2UF	50*105
	25UF	45*75		35+5UF	50*105
	30UF	45*85		35+7.5UF	50*105
	30UF	45*100		36+2UF	50*100
	30UF	50*75		36+4UF	50*100
	35UF	50*85		36+6UF	50*100
	35UF	45*85		40+5UF	50*120
	35UF	50*100		40+7.5UF	50*120
	36UF	50*95		45+2UF	50*105
	40UF	50*85		45+4UF	50*105
	40UF	50*100		45+5UF	55*110
	45UF	50*100		45+6UF	50*105
	45UF	50*110		45+5UF	50*125
	50UF	50*100		45+7.5UF	50*125
	50UF	50*110		50+2UF	50*105
	55UF	50*100		50+4UF	50*105
	55UF	50*110		50+5UF	50*125
	60UF	50*110		50+6UF	50*105
	60UF	50*125		50+6UF	50*125
	70UF	55*125		50+7.5UF	50*125
	80UF	55*125		55+5UF	50*125
	100UF	55*125		55+6UF	50*125
