Project Description

CBB60 AC capacitor

CBB60 COHERER POLYPROPYLENE CAPAClTORS SERlES

Main Feature:

Low dissipation factor,small inherent temperature rise.excellent self-healing stability,safety and high voltage withstand,etc.

Applications:

Used widely in washing machine,water pump,air conditioner and as well household electric appliances etc. to start and run single phase motors in alternating current usage.



Techinnical Parameters:

Capacitance range

1-150μf

Rated voltage Un

250v.ac/400/450V.ac

Rated frequency

50Hz;60Hz

Capacitance tolerance

±5%;±10%

Climatic category

-25+70°C

Dissipation factor(at 50Hz-Hz and 20°C)

≤0.002(100Hz,20°C)

Test voltage between terminals

2×Un for 3s

Test voltage between terminals and case

2×Un+1000VDC FOR 2s

Reference standard

EN 60252-1:2001;IEC252



Outline size

Rated Capacitance(μf }

250V. ac

400 V. ac-450 V. ac

ΦDH x (mm)1

ΦD x H(mm)2

ΦDH x (mm)1

ΦD x H(mm)2

3

Φ30x60

Φ32x55

Φ30x60

Φ32x55

4

Φ30x60

Φ32x55

Φ30x60

Φ32x55

5

Φ30x60

Φ32x55

Φ30x60

Φ32x55

6

Φ30x60

Φ32x55

Φ30x60

Φ32x55

7

Φ34x63

Φ36x58

Φ34x63

Φ36x58

8

Φ34x63

Φ36x58

Φ34x63

Φ36x58

9

Φ34x63

Φ36x58

Φ34x63

Φ36x58

10

Φ34x63

Φ36x58

Φ34x63

Φ36x58

12.5

Φ34x68

Φ36x70

Φ34x68

Φ36x70

15

Φ38x73

Φ36x70

Φ38x73

Φ36x70

16

Φ38x73

Φ36x70

Φ38x73

Φ36x70

18

Φ38x73

Φ40x70

Φ38x73

Φ40x70

20

Φ42x75

Φ40x70

Φ42x75

Φ40x70

25

Φ45x94

Φ45x92

Φ45x94

Φ45x92

*Special requirement can be fulfilled at the request Of Customers






1.Q:Are you a factory or a trading company?
A:capacitor Manufactory.

2.Q: How about your quality of capacitors?
A:Producats through the industry's top customers, a number of national customer verificatiom,stable and reliable quality.

3. Q: What are your payment terms?
A:T/T

4. Q: How about the packing of this model?
A: Carton packing or as your requirement.

5. Q: About the customers response?
A: They always become our regular customers.And become good friend.

6. Q: What is your delivery time?
A:It depends on your order.Normally 20-30days for standard.

7. Q: How about the shipping time?
A: Usually it will take 4-10days for Express,7-15days for Air,25-55days for Sea,it also depends on the destination area.

8. Q: How do you guarantee your quality?
A: we have TUV RoHS CE and CQC certificates.And we ues a lot of time to test the product.
